2 nd Generation Powered auto-cable manager Marine ROV
Every under water ROV drone needs a cable for telemetry and position control. These can be over 300M long and can easily become tangled, so a cable winder helps keep things organized. This secondary development and testing phase, incorporated key elements from the previous winder design we produced for the client, with the goal of reducing the package size and weight whilst at the same time boosting performance.
direct drive winder close beach 2
Numerous proof of performance test rigs allowed us to evolve the control system alongside the mechanism.. During power assisted wind-out the user in effect closes the control systems feedback loop, allowing cable to be pulled effortlessly at any speed.
Rapid prototype testing
